A stud bolt is a mechanical fastener consisting of a threaded rod with no head. It is designed to be used with two nuts, one on each end, to create a secure and firm connection between two components. Unlike regular bolts, which have a head on one side, stud bolts provide better load distribution, higher tensile strength, and enhanced reliability in high-pressure and high-temperature applications.
Stud bolts are widely used in piping systems, pressure vessels, heat exchangers, construction, automotive, aerospace, and marine industries. Their ability to provide superior clamping force makes them an essential component in critical operations.
Types of Stud Bolts
Depending on their application, stud bolts are available in multiple types:
1. Full Threaded Stud Bolts
- These bolts are threaded throughout their entire length, providing maximum grip strength.
- Commonly used in flange joints, piping connections, and structural applications.
2. Tap-End Stud Bolts
- Feature two different thread lengths, with a shorter thread on one end and a longer thread on the other.
- Used in machinery assemblies, turbine casings, and pressure vessels.
3. Double-End Stud Bolts
- Have equal-length threads on both ends, allowing nuts to be fastened on either side.
- Used in structural applications, heavy equipment, and industrial machinery.
4. Reduced Shank Stud Bolts
- Have an unthreaded portion in the middle, reducing weight and increasing flexibility.
- Preferred in automotive, aerospace, and offshore industries where vibration resistance is needed.
5. Flange Stud Bolts
- Specifically designed for connecting flanges in piping systems.
- Used in oil & gas, petrochemical, and chemical processing plants.
Materials and Grades of Stud Bolts
The performance of a stud bolt heavily depends on the material composition and grade. Vision Alloys manufactures stud bolts in a wide range of materials to meet various industrial requirements.
Common Stud Bolt Materials
✅ Carbon Steel Stud Bolts – Cost-effective and widely used in construction, bridges, and general engineering applications.
✅ Stainless Steel Stud Bolts – Offer excellent corrosion resistance, ideal for marine, food processing, and pharmaceutical industries.
- SS 304 Stud Bolts (UNS S30400) – Standard stainless steel with excellent corrosion resistance.
- SS 316 Stud Bolts (UNS S31600) – Enhanced corrosion resistance due to molybdenum content.
- SS 321 Stud Bolts (UNS S32100) – Stabilized with titanium, ideal for high-temperature applications.
✅ Alloy Steel Stud Bolts – Known for high strength and durability, used in power plants, turbines, and automotive industries.
- ASTM A193 Grade B7 – Widely used in pressure vessels and pipelines.
- ASTM A193 Grade B16 – Suitable for extreme heat and high-pressure conditions.
✅ Super Duplex & Duplex Steel Stud Bolts – Offer high tensile strength, superior corrosion resistance, and excellent mechanical properties.
- Super Duplex S32750 Stud Bolts – Commonly used in offshore oil & gas, desalination plants, and chemical processing.
- Duplex S31803 & S32205 Stud Bolts – Ideal for marine environments, shipbuilding, and heat exchangers.
✅ Nickel Alloy Stud Bolts – Designed for extreme environments, high temperatures, and aggressive chemical exposure.
- Inconel 625 Stud Bolts – Resistant to oxidation and pitting corrosion.
- Monel 400 Stud Bolts – Excellent resistance to saltwater and acidic environments.
- Hastelloy C276 Stud Bolts – Used in aerospace, chemical industries, and nuclear reactors.
Stud Bolt Grades & Standards
Stud bolts are manufactured according to ASTM, ASME, DIN, and ISO standards to ensure they meet industrial requirements.
| Grade | Material Type | Application |
|---|---|---|
| ASTM A193 B7 | Alloy Steel | High-pressure piping, petrochemical plants |
| ASTM A193 B16 | Alloy Steel | Boilers, turbines, heat exchangers |
| ASTM A320 L7 | Alloy Steel | Cryogenic applications, LNG plants |
| ASTM A453 660 | High-Strength Steel | Aerospace, nuclear reactors |
| ASTM F593 | Stainless Steel | Marine, food & beverage, pharmaceuticals |
| DIN 975 | Various | General construction, heavy machinery |
At Vision Alloys, we ensure that all our stud bolts meet strict quality standards and undergo rigorous testing for reliability and durability.
Applications of Stud Bolts
Stud bolts are used in various industries where strong, secure, and corrosion-resistant fastening is required.
1. Oil & Gas Industry
- Essential in pipeline connections, drilling rigs, and offshore platforms.
- High-strength stud bolts (ASTM A193 B7, B16) are used in extreme pressure conditions.
2. Petrochemical & Chemical Processing
- Used in pressure vessels, heat exchangers, and reactors.
- Duplex and super duplex stud bolts resist corrosion from harsh chemicals.
3. Power Plants & Boilers
- Secure high-temperature boilers, steam turbines, and nuclear reactors.
- Nickel alloy stud bolts withstand extreme thermal conditions.
4. Construction & Infrastructure
- Provide durable connections in bridges, buildings, and heavy machinery.
- Carbon steel stud bolts offer cost-effective structural fastening.
5. Marine & Shipbuilding
- Used in submarine hulls, offshore structures, and ship decks.
- Stainless steel and super duplex stud bolts resist seawater corrosion.
6. Automotive & Aerospace
- Found in engine assemblies, aircraft structures, and suspension systems.
- Reduced shank stud bolts minimize weight while ensuring high strength.
Why Choose Vision Alloys for Stud Bolts?
At Vision Alloys, we manufacture and supply high-quality stud bolts designed to meet the toughest industrial demands. Our stud bolts are made from premium raw materials and are tested for tensile strength, corrosion resistance, and durability.
Key Benefits of Our Stud Bolts
✅ Wide Range of Materials & Grades – From carbon steel to exotic alloys.
✅ Custom Manufacturing – We produce stud bolts in various sizes and specifications.
✅ Corrosion & Heat Resistance – Ideal for harsh industrial environments.
✅ ISO & ASTM Standards Compliance – Ensuring top-tier quality and reliability.
✅ Global Supply & Competitive Pricing – Serving industries worldwide.
For bulk orders, technical consultations, or customized stud bolts, contact us today!
📧 Email: [email protected]
Conclusion
Stud bolts are an essential component in industrial applications where secure, high-strength, and corrosion-resistant fastening is required. Whether used in flanges, machinery, piping systems, or structural frameworks, choosing the right material and grade ensures optimal performance.
Vision Alloys is a trusted manufacturer and supplier of premium-quality stud bolts, offering customized solutions tailored to specific industry needs. Contact us today to get the best-quality stud bolts at competitive prices.
